RadioDetection LMX200™ GPR

The LMX200™ provides unprecedented insights and target confidence to detect traditionally non-locatable subsurface features such as:

• Non-metallic pipes, including PVC and asbestos cement
• Underground Electrical Cable
• Concrete storm and sewer systems
• Utilities where installed tracer wiring has failed
• Underground storage tanks and drainage tiles
• Septic system components
• Non-utility structures such as vaults, foundation walls and concrete pads

Optional external GPS

Higher accuracy geo-referencing of targets for post processing in CAD and GIS software

Enhanced on-site capabilities

Capabilities include: Line Scan mode with SplitView, Grid Scan, MapView, Wi-Fi on-site mini reports

High visibility touch screen

A resistive touch screen that works with gloves on, with user selectable languages and metric and US standard options.

Produce and share instant on-site reports

Share directly from your display unit with built-in Wi-Fi. Option to add data markers to highlight points of interest.

USB port

A USB port allowing for easy data transfer for further data analysis.

Lightweight build

A lightweight fiberglass cart frame build making transportation easy. No metal in the build reduces interference with GPR signals.

Lead acid gel battery

A long lasting and swappable battery.

GPR Sensor

Patented ultra-wideband (UWB) 250 MHz GPR antenna and DynaT for dynamic target enhancement.

Weight & Dimensions:

• Size: 100 x 70 x 115 cm (39.4 x 27.6 x 45.3 in)
• Weight: 22 kg (48 lbs)
• Display Unit size: 21 cm (8 in) diagonal

Power:

• 12 volt sealed lead acid gel cell
• Battery Capacity: 9.0 Ah
• Battery Weight: 3.6 kg (7.9 lbs)
• Battery Life: 4-6 hours
• Charger: 110-240V

Environmental & Temperatures

• Ruggedized, environmentally sealed unit and connections: IP65
• Operating temperature range: -40°C to +50°C (-104°F to 122°F)

Regulatory Specifications: Meets FCC 15.509, IC RSS-220 and ETSI EN-302066

Data Storage: 380 km (236 miles) of data

Depth: Up to 8 meters (26 feet)
