Teltonika Telematics TAT100 Mini GPS Tracker

Teltonika TAT100 is an advanced tracking solution with a 2G (GSM) compatibility. Equipped with a robust, practical and water-resistant (IP68) enclosure and different mounting accessories, the tracker is extremely easy to install and use. As it is developed on a low power Bluetooth chipset, long battery life provides endless possibilities in various use cases. With the features in hand, one can monitor non-powered assets, such as: construction equipment, tools, wire reels, elevators, and many more. On top of that, TAT100 serves as a backup vehicle tracker, or even as a stand-alone wireless tracker.

1 REPORT PER DAY – UP TO 3 YEARS*

Long-lasting battery life and the ability to stay offline on a smart sleeping mode make this solution unique in preventing vehicle theft

* Battery life may be affected by various factors, such as signal strength, etc.

PROTECTION AGAINST WATER AND DUST IN EXTREME WEATHER CONDITIONS

The IP68-rated enclosure ensures reliable operation in any climate and under severe temperature deviations

EFFICIENT CAR THEFT PREVENTION

Easy to hide anywhere in a vehicle thanks to a compact size, while sleep mode protects against detecting tracker by thieves

BACKUP TRACKING THE EASY WAY

Quick set-up with Teltonika vehicle tracking devices to use TAT100 as a backup tracker for your transport’s maximum safety

PRODUCT SPECIFICATIONS

GNSS

• GNSS: GPS, GLONASS, GALILEO, BEIDOU
• Receiver: 33 channel
• Tracking sensitivity: -165 dBM
• Position Accuracy: < 2.5 m CEP

Cellular

• Technology: GSM/GPRS
• 2G bands: Quad-band 850 / 900 / 1800 / 1900 MHz
• Data transfer: GPRS Multi-Slot Class 12 (up to 85,6 kbps)
• Data support: SMS (text/data)

Power

• Internal battery: Extremely low self-discharge Li-SOCl2 swappable, non-rechargeable battery, 7,2V 2200mAh (10,8V 2200mAh version available)

Bluetooth

• Specification: 4.2 + LE
• Supported peripherals: EYE sensors, Beacons, Universal BLE sensor support

Physical specification

• Dimensions: 78 x 63 x 28 mm (L x W x H)
• Weight: 119 g (when 2 cell batteries are used)

Interface

• GNSS: antenna Internal High Gain
• Cellular antenna: Internal GSM High Gain
• USB: 2.0 Micro-USB
• LED indication: 2 status LED lights
• SIM: Micro-SIM
• Memory: 128MB internal flash memory

Operating environment

• Operating temperature: (without battery) -20 °C to +60 °C
• Battery discharge temperature: -60 °C to +85 °C
• Battery storage temperature: Recommended max 30°C
• Ingress Protection Rating: IP68

Features

• Scenarios: Accelerometer wake up, GNSS and LBS, Bluetooth® sensor support, Recovery mode, Periodic tracking on stop / on move, Scheduler with time zones, Backup tracking, Static navigation, Lost BLE sensor
• Sensors: Accelerometer
• Sleep modes: Single custom sleep mode
• Configuration and firmware update: FOTA Web, Teltonika Configurator (USB)
• SMS: Configuration, Events, Debug
• GPRS commands: Configuration, Debug
• Time Synchronization: GNSS, NITZ, NTP

Certification & approvals

• Regulatory CE/RED E-Mark EAC UKCA UA.TR REACH

Standard package contains

• TAT100 tracker
• Packaging box with Teltonika branding
