Construction Lasers 10 products.

The Geomax MR240 Machine Control Receiver provides exact grade data for all visual machine control applications, with an extended range of up to 656 feet. It is perfect for use with backhoes, mini excavators, and other machines. With a 240-degree reception angle, this wireless receiver two detection accuracies - fine and coarse.

Highlights:

• Extensive Range up to 656 feet
• 240° Reception Angle
• Wireless laser receiver
• Powerful earth magnets w/ attractive mounts
• LED indicators
• Detection accuracies: Fine and Coarse
• Tough with IP67 rating water resistance
• Battery life up to 130 hours

The Geomax MD360 Remote Display provides an in-cab visualization that works with the MR360R machine control receiver. Featuring the latest radio frequency technology, this remote display offers wireless bi-directional communication which allows the user to change machine control receiver settings without leaving the cab. Also, it comes with nine display channels for a more reliable grading operation.

Highlights:

• Works with MR360 machine control receiver
• Wireless radio frequency link
• Display channels: 9
• Vertical indicator
• Menu choices
• Heavy-duty suction cup mount

The Geomax Zone20 H Self-Leveling Rotary Laser is a versatile rotary laser for all surveying and engineering applications. This construction tool has a range of up to 3,000 feet with an accuracy of ±3/32-inch at 100 feet. It can perform horizontal self-leveling within ±6 degrees and manual slope in two axes. It also offers three receiver options to increase functionality and enhance accuracy.

Highlights

• Range up to 3,000 feet with laser receiver Ø
• Self-leveling within ±6 degrees
• Accuracy ±3/32 inch at 100 feet
• Audio indicator
• Tilt alert control
• Dustproof and water resistant to IP67
• Battery life up to 40 hours
• Thread 5/8-11

The one-button Zone40 T laser offers the precision, range, and durability of the Zone60 but without the need for adding grade. The rotating head is completely sealed to keep the laser working in the toughest conditions and to contribute to the instrument's outstanding IP67 environmental rating.

The Geomax Zone20 HV Self-Leveling Rotary Laser is a versatile rotary laser for all surveying and engineering applications. This construction tool has a range of up to 3,000 feet with an accuracy of ±3/32-inch at 100 feet. It can perform horizontal & vertical self-leveling within ±5 degrees and manual slope in two axes. It also offers three receiver options to increase functionality and enhance accuracy.

Highlights

• Range up to 3,000 feet with laser receiver Ø
• Self-leveling within ±5 degrees
• Accuracy ±3/32 inch at 100 feet
• Audio indicator
• Tilt alert control
• Dustproof and water resistant to IP67
• Battery life up to 40 hours
• Thread 5/8-11

The GeoMax MR360 offers accurate grade information for all visual machine control applications.

Highlights:

• Large 360° detection windows pick up any rotating laser, from any angle.
• Built-in vertical indicator monitors angle of the stick, signaling if it’s plumb or under- or over-extended.
• Magnet mount allows quick setup and easy movement from machine to machine.
• The optional display unit MD360 enables wireless transmission of the display in the machine cabin.

The GeoMax Zone60 HG Semi-Automatic Dual Grade Laser features an easy-to-use, dial-in grade that provides more dependability in daily use. It enables semi-automatic grade in leveling applications with a working range of up to 3,000 feet with a laser receiver. The Zone60 HG is specifically designed for construction workers who need the dependability and accuracy of a fully professional grade laser on a daily basis. With an accuracy of ±1/16-inch at 100 feet, the Zone60 HG is ideal for concrete pouring and interior formwork.

Highlights

• Range up to 3,000 feet with laser receiver Ø
• Accuracy: ±1/16-inch at 100 feet
• Dial-in grade range of ±8%
• Rotation speed of 600 rpm
• Horizontal self-leveling ±5 degrees
• IP67 dustproof & water immersible
• Battery life up to 40 hours

The GeoMax MR360 offers accurate grade information for all visual machine control applications.

Highlights:

• Large 360° detection windows pick up any rotating laser, from any angle.
• Built-in vertical indicator monitors angle of the stick, signaling if it’s plumb or under- or over-extended.
• Magnet mount allows quick setup and easy movement from machine to machine.
• The optional display unit MD360 enables wireless transmission of the display in the machine cabin.

The GeoMax Zone60 DG Fully-Automatic Dual Grade Laser is a fully-automatic device designed for construction workers who need the dependability of a professional grade laser on a daily basis. With a working range of up to 3,000 feet, the Zone60 DG also boasts an accuracy of ±1/16-inch at 100 feet. The Zone60 DG self-levels within ±5 degrees in both horizontal and vertical direction.

Highlights

• Range up to 3,000 feet with laser receiver Ø
• Dual grade to ±15%
• Self-leveling within ±5 degrees
• Accuracy of ±1/16 inch at 100 feet
• Adjustable rotation speeds: 300 & 600 RPM
• Battery life up to 40 hours
• IP67 dustproof and water resistant

Easily perform leveling tasks over great distances with the Geomax Zone75 DG Fully-Automatic Dual Grade Laser. This rotary laser provides the same high-level performance as Zone80 (phased out in 2021) but with a reduced rotation speed of 900rpm, enabling it to produce a more stable beam at distances of up to 550 meters away from the laser. This makes it a great choice for land leveling and agriculture applications.

Highlights

• Working range up to 3,600 ft. (1100 m)
• Grade range: up to ±15%
• Fully automatic in both axes
• Adjustable rotation speed up to 900 rpm
• Horizontal self-leveling within ±5°
• Accuracy: ±1/16 inch at 100 feet
• Optional remote control and receiver
• Battery life up to 50 hours
