World's First AnchorX Smart Omnidirectional Anti-Current System
This function activates when e-PTZ and DVL work together.
OctoDrive Power Layout
The newly innovative OctoDrive power system, featuring eight thrusters in a vector layout, provides high response speed and strong stability. This system allows for 360-degree full-range movement and rotation while maintaining a leading speed of 4.5 knots, making maneuvering precise and effortless.
The self-developed magnetic coupling thrusters are compact, powerful, and easy to maintain, preventing sanding and salt build-up, ensuring stable and reliable underwater operations in various environments.
World's First AnchorX Smart Omnidirectional Anti-Current System
Intelligently identify: Current direction and speed
Intelligently employ: Maximum anti-current direction
2.3 m/s: Max currents resistance capabilit
Innovative underwater e-PTZ for Stable Panoramic Shooting
Stable Vision Despite Position Changes
Combining the e-PTZ with the AnchorX Smart Omnidirectional Anti-Current System, When the CHASING X changes its posture, the e-PTZ camera automatically corrects its level, ensuring the target remains in focus and the image stable.
360° all-around shooting with one-click flipping; 180° hemispherical view, the framing screen is adjustable
Through CHASING WSRC, users can manually adjust the framing screen during shooting. The stored panoramic data supports dragging the image to view details of other positions in the scene.
Modular Design
The propellers, battery modules, fill lights, camera, control cabinet and distance-lock sonar are designed with a modular approach, ensuring stability and reliability during long-duration, high-intensity operations, while also making after-sales service easier.
CHASING X supports the secondary development of AI-related functions based on this platform
CHASING X supports the secondary development of AI-related functions based on this platform
- Intelligent identification
- Intelligent obstacle avoidance
- Intelligent measurement
- Intelligent cruise Intelligent tracking
- Intelligent flaw detection
SDK Open Platform
Support Customization and Development in multi-scenarios
Supports the mounting of grabber arm, multi-beam imaging sonar, USBL, DVL, laser-scaler, etc., with flexible configurations and rapid assembly and disassembly, catering to the needs of multiple industries and scenarios.
350-Meter Diving Depth
Maximum diving depth of 350 meters and a horizontal operational radius of 400 meters, CHASING X is well-suited for deep-sea exploration and observation.
Next-Generation Low-light Lens
Specially designed for dark environment, the optimized image algorithm enhances low-light conditions, delivering clear, stable, and color-accurate visuals.
12,000 Lumens Floodlight
Enhances shooting in low-light environments.
Dual Power Supply for Uninterrupted Operation
The standard 1000Wh lithium battery supports quick replacement for continuous operation, with the option for shore-based power supply for unlimited runtime.
Protective Frame Design
A high-strengh material frame effectively protects the main unit and accessories from direct impacts, while also enhancing portability.
User-Friendly Interaction and Superior Operation Experience
Equipped with a professional-grade waterproof-screen remote control ,CHASING X connects and operates seamlessly with the dedicated CHASING GO1 APP for CHASING X. It supports live streaming of underwater footage and one-click sharing for a more user-friendly experience
ROV Specifications
- Size: 810 x 636 x 453 mm
- Max Depth: 350 meters (1148 ft)
- Max Flow Resistance: 2.3 m/s
- Runtime: Up to 2 hours (normal operation)
- Battery: 1000 Wh
- Power Supply: Battery / C-SPSS (Optional)
- Operating Environment: Underwater
- Operating Temperature: -10°C ~ 45°C
WSRC Specifications
- Size: 292 x 156 x 79 mm
- Weight: 1.3 kg
- Battery Capacity: 7000 mAh
- Runtime: ≥6 hours (depending on the environment)
- Wireless: Wi-Fi supported
- HDMI: Supported
- Waterproof Rate: IP65
Sensors Specifications
- IMU: Axis gyro / accelerometer / compass
- Depth Sensor: Accuracy ＜±0.25 m
- Temperature Sensor: Accuracy ＜±2°C
LED Specifications
- Brightness: 2 x 6000 lm
- Dimming: Stepless (brightness adjustable via App)
Camera Specifications
- CMOS: 1/1.8"
- Lens: F2.2
- Focusing Distance: 0.5 m
- Field of View (FOV): 160°
- Max Resolution: 8 Megapixel
- Image Format: JPEG/DNG
- Video Resolution:
- UHD: 3840 x 2160, 4K / 30 FPS
- FHD: 1920 x 1080 (1080P), 30/60/120 FPS
- Slow Motion:
- 720P: 6x (180 FPS)
- 1080P: 4x (120 FPS)
- Time Lapse: 4K / 1080P supported
- Video Stream: 60 M
- Video Format: MP4
- SD Card: Standard 128 GB, supports up to 1 TB (removable)
ePTZ Specifications
- CMOS: 1/1.8"
- Lens: F2.0
- Focusing Distance: 0.5 m
- Field of View (FOV): 220°
- Max Resolution: 8 Megapixel
- Image Format: Panoramic JPEG
- Video Stream: 60 Mbps
- Video Format: Panoramic MP4
- Video Resolution: UHD: 3840 x 1920, 25 FPS
- SD Card: Standard 128 GB, supports up to 1 TB (removable)
